Specification | Details |
---|---|
Button | N/A |
External Power Supply | 12V / 1A |
Antenna | 2x Detachable External 4G LTE Antennas |
Interface | 3x 10/100Mbps LAN Ports, 1x 10/100Mbps LAN/WAN Port, 1x Nano SIM Card Slot, 2x External SMA-F Antenna Interface |
Wireless Standards | IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz |
Dimensions (W x D x H) | 174 x 124.5 x 33.5 mm |
Frequency | 2.4 GHz and 5 GHz |
Signal Rate | 300 Mbps at 2.4 GHz, 433 Mbps at 5 GHz |
Reception Sensitivity | 5 GHz: - 11a 54M: -78 dBm - 11ac VHT20 MCS0: -92 dBm - 11ac VHT20 MCS8: -72 dBm - 11ac VHT40 MCS0: -90 dBm - 11ac VHT40 MCS9: -67 dBm - 11ac VHT80 MCS0: -87 dBm - 11ac VHT80 MCS9: -64 dBm 2.4 GHz: - 11g 54M: -74 dBm |
Wireless | IEEE 802.11b/g/n/ac |
Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
Certification | CE, RoHS |
System Requirements | Windows 98SE / NT / 2000 / XP / Vista / 7 / 8 / 8.1 / 10, macOS, NetWare, UNIX or Linux, Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 or other Java-enabled browser |
Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
Storage Temperature | -40°C ~ 60°C (-40°F ~ 140°F) |
Operating Humidity | 10% ~ 90% (non-condensing) |
Storage Humidity | 5% ~ 90% (non-condensing) |
Warranty | 3 Years |
Option | N/A |
